Intel Wireless-AC 9462 IEEE 802.11ac Bluetooth 5.0 Wi-Fi/Bluetooth Combo Adapter for Notebook 9462.NGWG.NV

Intel Wireless-AC 9462 IEEE 802.11ac Bluetooth 5.0 Wi-Fi/Bluetooth Combo Adapter for Notebook 9462.NGWG.NV

For a custom quote please email sales@ziestech.com

Integrated Wi-Fi and Bluetooth®. Optimized Solution for System Design.

Intel® Wireless-AC 9462 adapter is a CRF (Companion RF module) supporting the 1st generation integrated Intel wireless 802.11ac solution comprised of CNVi and a CRF. The solution provides Bluetooth® 5 and 1x1 802.11ac Wi-Fi including wave 2 features such as downlink MU-MIMO. It offers enhanced features such as antenna diversity and is more cost-effective than the previous-gen Intel 802.11ac 1x1 products. Combined with Intel® Core™ processors and exceptional Intel wireless innovations, the Intel Wireless-AC 9462 dramatically improves your connected experience at home, work or on the go.

1ST GENERATION INTEGRATED 802.11AC WIRELESS

Faster Speed Better Coverage Larger Capacity 802.11ac, 1x1, Dual Band, 80MHz, MU-MIMO

Delivers up to 3x faster Wi-Fi speed (up to 433 Mbps) than 1x1 802.11n, with up to 3x bandwidth for more users and devices. Advanced optional 802.11ac specification features and improved RF KPIs that enhance channel reliability and Wi-Fi performance result in better coverage and user experience. Intel® Wireless-AC 9462 enables smooth streaming of high-resolution videos, fewer dropped connections and less congestion, and fast speeds farther away from the router.

Downlink MU-MIMO allows an access point to simultaneously transmit data to multiple clients and can improve overall downlink network capacity potentially by over 3x.

Bluetooth® 5

Bluetooth® 5 provides 4x range over Bluetooth® 4.2 with the same power, enabling coverage throughout the home. Bluetooth® 5 also doubles the transmit speed for faster transmissions, thereby reducing the overall power. Bluetooth® 5 also adds new enhanced data broadcasting enabling seamless services such as location-based services and simpler pairing for Bluetooth® wireless technology enabled products.

Antenna Diversity

The Intel® Wireless-AC 9462 adapter can be used in dual antenna platforms and provides antenna diversity support. This means the adapter dynamically chooses the better antenna to connect to and provides a robust connection for the platform.

Microsoft Windows 10 Ready

Full support for latest Microsoft Windows 10 OS.

Form Factors (M.2 2230 and 1216)

M.2 2230 modules enable system configuration and platform usage flexibility with the use of a standard Key E socket for attaching the module.

M.2 1216 modules enable platform design optimization with the use of an Intel® CNVi interface between the integrated MAC and integrated Intel® Wireless-AC 9462 module, providing savings on motherboard space, BOM, PCIe and DP lanes, plus allowing for flexible motherboard routing up to 10".

EXPERIENCE THE INTEL® DIFFERENCE

Worldwide Regulatory Support Intel® Dynamic Regulatory Solution

Enables worldwide regulatory compliance on a single adapter SKU. The Intel® Wireless-AC 9462 detects its location and automatically optimizes the Wi-Fi settings to local regulatory requirements, maximizing performance in each geography and simplifying travel experience and global enterprise procurement. Future regulatory changes are easily managed during the product life cycle.

Wireless Functionality in Pre-boot Environment

Support for Wi-Fi network and Bluetooth® Low Energy Human Interface Device (HID) connectivity in the platform's Unified Extensible Firmware Interface (UEFI) environment during its boot stage. This capability enables use cases like OS recovery over Wi-Fi and Bluetooth® Low Energy-based keyboard and mouse connectivity in this pre-boot environment.

  • With the IEEE 802.11ac standard and up to 433 Mbit/s data transfer rates, this wi-fi/bluetooth combo adapter enables efficient network performance
  • Plug into an M.2 slot on your device for instant wireless connectivity
  • Want a top-notch wireless solution for a single desktop PC? Simply slot the adapter into any free internal socket on your desktop PC and connect to an available wireless connection
